MIL-DTL-53078A
TABLE III. Test schedule.
Test
First
Quality
Test
Requirement
Order
Article
Conform
Paragraph
Paragraph
Test
1
2
3
4
5
6
1
X
X
Input power
4.5.3.1
3.4.1.1
2
X
X
Signal processing
4.5.3.2
3.4.1.2
3
X
X
Noise level
4.5.3.3
3.4.1.2.1
4
X
X
Structural adapter
4.5.3.4
3.4.2
5
X
X
Electromagnetic
4.5.4
3.5.5.1
compatibility
6
X
X
Bonds and grounds
4.5.5
3.5.6
7
X
Reliability
4.5.6
3.5.7
8
X
Maintainability
4.5.7
3.5.8
9
X
Low temperature
4.5.8.1
3.6.1.1
10
X
X
High temperature
4.5.8.2
3.6.1.1
11
X
Storage temperature
4.5.8.3
3.6.1.2
12
X
Vibration
4.5.9
3.6.2
13
X
Basic shock
4.5.10
3.6.3
14
X
Ballistic shock
4.5.11
3.6.4
15
X
High intensity shock
4.5.12
3.6.5
16
X
X
Submergence
4.5.13
3.6.6
17
X
Cleaning spray
4.5.14
3.6.7
4.5.3.2 Signal processing. As specified in 3.4.1.2, apply an input signal of
350 (+35, -0.0) mVp-p at a frequency of 50.0 (±5.0) Hz between J1-E and J1-F. Measure and
verify the output at terminals J1-H (positive) and J1-C (return) has the following characteristics:
1. Maximum pulse amplitude of 17.0 to 30.0 Vdc and minimum pulse amplitude of
0.3 ±0.2 Vdc.
2. The duration of the maximum amplitude portion of output signal shall be
±1.0 milliseconds.
3. The period of the output signal shall be 13.06 (+1.45, -1.19) seconds.
Repeat the above test with an input frequency of 1000 ±100 Hz in place of the 50.0 Hz.
NOTE:
For an input frequency of 1000 ±100 Hz the period (Item 3) shall be 0.653
(+0.726, -0.594) seconds.
Repeat the complete sequence of tests with an input signal of 5.0 (+0.0, -0.5) Vp-p in place of the
350.0 mVp-p signal.
