MIL-DTL-46789D(AT)
6
5
4
180 Hz
9.9 Hz
3g
3
0.5 in. D.A.
2g
2
1.5g
1g
10
9
8
7
6
5
0.5g
4
3
2
1
1
2
3
4
5 6 7 8 9 10
2
3
4 5 6 7 8 9 10
2
3
4
5 6 7 8 9 10
100
500
Frequency (Hz)
FIGURE 2. Vibration profile.
3.7.7 Temperature stability. The assembly shall meet the requirements specified herein
at ambient temperatures ranging from -32 °C to 52 °C and shall show no evidence of failure,
electrical or mechanical, after storage at an ambient temperature ranging from -54 °C to -8 °C
(see 4.9.7 and 4.9.8).
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are
classified as follows:
a. First article inspection (see 4.1.1)
1. Preproduction inspection (see 4.1.2)
2. Initial production (see 4.1.3)
b. Conformance inspection (CI) (see 4.2)
1. Examinations (see 4.2.2)
2. Tests (see 4.2.3)
7
