MIL-PRF-62365C(AT)
b. A hydraulic test facility capable of permitting motor operation at all mounting
attitudes; continuous, intermittent, reversing and stalled operation in either
direction of rotating and application of loads on the motor shaft up to 30 lb-in.
c. Instrumentation necessary for measuring, motor rpm, motor torque, oil pressure,
oil flow rates, oil temperature, and leakage.
d. All gages and measuring devices shall be accurate within +5% of full scale.
4.3 First article inspection. First article inspection shall be performed on preproduction
or initial production samples as specified in table III (see 3.1).
4.3.1 Preproduction inspection. When specified (see 6.2), the preproduction sample
shall consist of two hydraulic motors. Preproduction inspection shall consist of examination as
specified in 4.4.1.3 and tests specified in table III.
4.3.2 Initial production inspection. Unless otherwise specified (see 6.2), the Government
shall select two samples, from the first 10 hydraulic motors produced under the production
contract for initial production inspection. Initial production units shall be examined as specified in
4.4.1.3 and tested as specified in table III.
4.4 Conformance inspection.
4.4.1 Sampling. Sampling for inspection lots and sampling for examination of
conformance, see 6.5.
4.4.2 Materials and design. Conformance to 3.2 thru 3.3.12 shall be determined by
inspection of contractor records providing proof of certification that materials and design conform
to requirements. Applicable records shall include drawings, specifications, design data, receiving
inspection records, processing and quality control standards, vendor catalogs and certifications,
industry standards, test reports, and rating data.
TABLE III. Classification of inspections.
Conformance
First
Test
Title
Requirement
Inspection
article 100%
Materials and finish
3.2 thru 3.2.4
4.4.1.3
X
Design and construction
3.3 thru 3.3.12
3.3.1
4.4.1.3
X
Fluid
3.3.2
4.2.4
X
X
Cleanliness 1/
3.3.3
4.4.1.3
X
Lubrication
3.3.8
4.4.1.3
X
4.5.1
X
Interchangeability
10
