INCH-POUND
MIL-DTL-46735C(AT)
31 August 1998
SUPERSEDING
MIL-PRF-46735B(AT)
26 March 1997
DETAIL SPECIFICATION
WINCH DRUM: VEHICLE MOUNTING
This specification is approved for use by the U.S. Army Tank-automotive
and Armaments Command, Department of the Army, and is available for
use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers requirements for power operated spur planetary and
planetary geared, heavy duty, drum type winches for use on military combat and tactical transport vehicles. The
winches are driven from the vehicle hydraulic system.
1.2 Classification. Winches will be of the following models, classes and capacities
including the drawing numbers as specified in table I (see 6.2).
TABLE I. Winch model, class and capacity.
Class
Model number
Drawing
Spur
Planetary
number
gear
gear
Capacity (tons)
1
2
12.5
15
17.5
30
45
U-35B
8738935
X
X
U-60B
8738936
X
X
U-90B
8738937
X
X
P-30
10908544
X
X
P-60
10904960
X
X
N/A
11641136
X
X
Beneficial comments (recommendations, additions, deletions) and any pertinent data which
may be of use in improving this document should be addressed to: U.S. Army Tank-automotive
and Armaments Command, ATTN: AMSTA-TR-E/BLUE, Warren, MI 48397-5000, by using
the Standardization Document Improvement Proposal (DD Form 1426) appearing at the end of
this document, or by letter.
AMSC N/A
FSC 2590
DISTRIBUTION STATEMENT A Approved for public release; distribution is unlimited.
.
