[INCH-POUND]
A-A-52502B
May 11, 2010
SUPERSEDING
A-A-52502A
January 16, 1998
COMMERCIAL ITEM DESCRIPTION
VALVE ASSEMBLY, POPPET, HULL
DRAIN-VEHICULAR, 3 INCH
The General Services Administration has authorized the use of this commercial item
description (CID) for all Federal agencies.
1. SCOPE. This CID covers requirements for a 3 inch (in.) hull drain poppet valve assembly,
which is used to drain water out of vehicles. The valve assembly consists of a valve, seat, spring,
and knob.
2. SALIENT CHARACTERISTICS
2.1 Materials. Material shall be as specified herein or of equivalent strength and characteristics.
The use of recovered material made in compliance with regulatory requirements is acceptable
provided that all requirements of this CID are met (see 3.1).
2.1.1 Seat and valve. The seat and the valve shall be made of aluminum, Unified Numbering
System (UNS) A03550, A03560, or A96061 (tempered T6). Both machined and unmachined
surfaces shall be anodized.
2.1.2 Knob. The knob shall be made of steel, UNS G10100 to UNS G10250, and zinc plated in
accordance with ASTM B633.
2.1.3 Spring. The spring shall be made of corrosion resistant steel wire in accordance with
ASTM A313/A313M.
2.2 Design and construction. The valve assembly shall be designed and constructed in
accordance with figures 1 thru 4.
Beneficial comments, recommendations, additions, deletions, clarifications, etc. and any data that
may improve this document should be sent to DAMI_STANDARDIZATION@conus.army.mil or
U.S. Army RDECOM, Tank Automotive Research, Development and Engineering Center,
ATTN: RDTA-EN/STND/TRANS MS #268, 6501 E. 11 Mile Road, Warren, MI 48397-5000.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil/online/.
AMSC N/A
FSC 2590
